| Size | Sq/Rect | 2mm (14G) | 1.45mm (16G) | 1.2mm (18G) | 0.95mm (19G) |
|---|---|---|---|---|---|
| 1/2″ (12.70) | 10*10 | 3.217 | 2.452 | 2.075 | 1.750 |
| 5/8″ (15.88) | 12.5*12.5 | 4.174 | 3.146 | 2.648 | 2.200 |
| 3/4″ (19.05) | 15*15 | 5.127 | 3.837 | 3.220 | 2.650 |
| 3/4″ (19.05) | 20*10 | 5.127 | 3.837 | 3.220 | 2.650 |
| 1″ (25.4) | 20*20 | 7.000 | 5.221 | 4.366 | 3.450 |
| 1″ (25.4) | 26*13 | 7.000 | 5.221 | 4.366 | 3.450 |
| 1″ (25.4) | 30*10 | 7.000 | 5.221 | 4.366 | 3.450 |
| 1.25″ (31.75) | 25*25 | 8.967 | 6.621 | 5.525 | 4.500 |
| 1.25″ (31.75) | 30*20 | 8.967 | 6.621 | 5.525 | 4.500 |
| 1.5″ (38.10) | 30*30 | 10.856 | 7.990 | 6.658 | 5.450 |
| 1.5″ (38.10) | 40*20 | 10.856 | 7.990 | 6.658 | 5.350 |
| 47.63 | 50*25 | 13.744 | 10.080 | 8.390 | 7.000 |
| 2″ (50.8) | 40*40 | 14.675 | 10.759 | 8.949 | 7.100 |
| 2.5″ (63.5) | 60*40 | 18.494 | 13.528 | 11.241 | 9.200 |
| 2.5″ (63.5) | 50*50 | 18.494 | 13.528 | 11.241 | 9.200 |
| 2.5″ (63.5) | 75*25 | 18.494 | 13.528 | 11.241 | 9.200 |
| 2.5″ (63.5) | 65*35 | 18.494 | 13.528 | 11.241 | 9.200 |
Grade : 200 & 300 Series
Certification : ISO / CE
Thickness : 0.8 To 2mm
Size : 3″(76.2mm) / 2.5″(63.5mm) / 2″(50.8mm) / (48mm) / 1.5″(38.1mm) / 1.25″(31.75mm) / 1″(25.4mm) / 3/4″(19.05mm) / 5/8″(16mm) / 1/2″(12.7mm) / (9.5mm)
Finish : Matt
Technique : Cold Rolled
Length : As Per Requirement
Country Of Origin : Made In India
Type : Welded
Brand : LPI
Customization : Available
Grade : 200 & 300 Series
Certification : ISO / CE
Thickness : 0.8 To 2mm
Size : 3″(76.2mm) / 2.5″(63.5mm) / 2″(50.8mm) / (48mm) / 1.5″(38.1mm) / 1.25″(31.75mm) / 1″(25.4mm) / 3/4″(19.05mm) / 5/8″(16mm) / 1/2″(12.7mm) / (9.5mm)
Finish : Matt
Technique : Cold Rolled
Length : As Per Requirement
Country Of Origin : Made In India
Type : Welded
Brand : LPI
Customization : Available
